61-5118-109 Details

OEM Make: TVS
Part Number: 61-5118-109
Dimensions: 8.38/11.44 x 12.75/16 x 26
Outside Diameter: 12.75" / 16.00"
Length: 26.00"
Inside Diameter: 8.38" / 11.44"
Top: Open
Bottom: Open
Shape: Conical
Approx. Square Footage of Filter Media: 222.64
Notes: The media for this TVS dust collector filter is 80/20 cellulose/polyester. (Select the 80/20 media option from the dropdown box above.) 80/20 is best to filter grinding dust, powder and dry chemical processing, and many other general manufacturing applications. Give us a call at (866) 393-0297 and we can help determine the proper filter media for your application.
