| Product Name
|
Silcon® |
| Material
|
Silicone |
| Product Type
|
Unreinforced Silicone Tubing - Peroxide Cured |
| ID
|
.375 (3/8) |
| OD
|
.625 (5/8) |
| Wall
|
.125 (1/8) |
| Available Lengths
|
100 |
| Working PSI (at 70°F)
|
10[T] |
| Burst PSI (at 70°F)
|
30 |
| Max Operating Temp(°F)
|
500 (NSF Max Operating Temp, 350°F) |
| Brittle Temp(°F)
|
-100 |
| Opacity
|
Translucent |
| Colors
|
Natural |
| Construction
|
Unreinforced |
| Shore Hardness(±5)
|
50A |
| Tensile Strength at Break(PSI)
|
1444 |
| Modulus at 100%
|
186 |
| Elongation at Break(%)
|
608 |
| Tear Resistance, Die B ppi
|
125 |
| Applications
|
Appliances, Beverage, Computer Manufacture, Deionized Water Transfer, Dental, Duplicating Equipment, Food, Gaskets, Seals, & 'O'-Rings, Hot Water Feeds, Insulation Sleeves, Laboratory, Medical, Peristaltic Pumps, Thermal Protection |
| Description
|
Unreinforced Silicone Tubing |
| Product Certifications
|
NSF-51 listed for food equipment materials[U] |
| Material Compliancy
|
Animal-Derived Ingredient Free, BPA Free, FDA 21 CFR 177.2600, Latex Free, Phthalate Free, REACH, RoHS |
| Footnote
|
[U] If used in an NSF application, the maximum operating temperature is limited to 350°F.
[T] Performed on hydrostatic test equipment at ambient temperature; based on the ASTM D1599 method. |
|
